PARAMETERS
Model |
CYW-250X |
CYW-350X |
Film Width |
Max 250mm |
Max 350mm |
Bag Length |
65~190/120~280mm |
|
Bag Width |
30~110mm |
50~160mm |
Bag Height |
Max 40mm |
|
Packaging Speed |
40~230bags/min |
|
Powder |
220V 50/60Hz 2.4Kw |
220V 50/60Hz 2.8Kw |
Machine Size (mm) |
L3920*W670*H1320 |
L4020*W720*H1320 |
Machine Weight |
800kg |
900kg |
MAIN FEATURES
1.Dual frequency conversion control, bag length can be set and cut in one step, save time and save film.
Human computer interface (HCI), easy for parameter setting.
2.Self checking function, fault self detected, clearly displays.
3.High sensitivity photoelectric eyes, color code tracking, digitizing input accurate positioning when
cutting and sealing.
4.Temperature controlled by independent PID, suitable for different packaging materials.
5.Position stops setting, no sticking knife.
6.Simple power train system, working reliable, easy for maintenance.
All controlled by software, easy for function adjustment and technology upgrade.
